  • I have AdGuard Home running on OPNSense as a local DNS with a wild card for for the ‘local domain’ pointing to Caddy

    in Caddy I have this section:

    *.<domain>.net {
    #header X-Frame-Options "SAMEORIGIN"
            tls internal
            encode gzip
            import sec-headers
            @sub1 host pve.<domain>.net
            @sub2 host kasm.<domain>.net
           ...
           handle @sub1 {
                    import sec-headers
                    reverse_proxy * https://10.1.1.11:8006/ {
                            transport http {
                                    tls_insecure_skip_verify
                            }
                    #       header_up Host {host}
                           header_up X-Real-IP {remote}
                           header_up X-Forwarded-For {remote}
                           header_up X-Forwarded-Port {server_port}
                           header_up X-Forwarded-Proto {scheme}
                    }
            }
            handle @sub2 {
                    import sec-headers
                    reverse_proxy  https://10.1.1.119/ {
                            transport http {
                                    tls_insecure_skip_verify
                            }
                    #       header_up Host {host}
                           header_up X-Real-IP {remote}
                           header_up X-Forwarded-For {remote}
                           header_up X-Forwarded-Port {server_port}
                           header_up X-Forwarded-Proto {scheme}
                    }
            }
    ...


  • Back up the server then work through:

    Just follow the guide https://iocaine.madhouse-project.org/documentation/3/getting-started/ Bind the iocaine service to 0.0.0.0:42069

    cat /opt/iocaine/etc/iocaine/config.d/00-server.txt.kdl
    http-server default {
      bind "0.0.0.0:42069"
      use handler-from=default
    }


    expose interface to Docker (make sure not to expose it to the world).

    sudo iptables -I INPUT 4 \
      -s 172.18.0.0/16 \
      -d 172.18.0.1 \
      -p tcp --dport 42069 \
      -j ACCEPT


    add the interface to the proxy service in a custom/docker-compose.yml.template

    proxy:
        {{COMPOSE_CADDY_IMAGE}}
        env_file:
          - ./caddy.env
          - {{ CADDY_EXTRA_ENV }}
        volumes:
          - ./caddy/Caddyfile:/etc/caddy/Caddyfile:ro
          - caddy_data:/data
          - caddy_config:/config
        extra_hosts:
          - "host.docker.internal:172.18.0.1"
    ...


    add iocaine to caddy in a custom/Caddyfile.template

    {$LEMMY_HOSTNAME} {
            import caddy-common

            ######################################
            ########## iocaine  code ##########
            @read method GET HEAD
                    reverse_proxy @read host.docker.internal:42069 {
                    @fallback status 421
                    handle_response @fallback
            }
    ...


    rebuild all the docler images (at least the caddy one ./deploy.sh -f) and test

    I think that should work

    CrowdSec
